0102P25 PNEUMO-HYDRAULIC PRESS 1.4T

This insert press is specifically designed for press-fitting various types of bushings.

It is hung and powered by compressed air. The air pressure is converted into hydraulic pressure by means of a suitable pump with a multiplication ratio.

Max pressure	220 bar
Compressed air range	3 - 8 bar
Max compression	1400 kg
Max stroke	75 mm
Air-oil pressure multiplication ratio	1 : 45
Oil capacity	1,4 lt
Noise at 1 meter	78 - 80 dB

Compression is ensured by a specific spring-return piston, whose stem exit speed is adjustable via a one-way throttle valve.

For safety reasons the device is equipped with double control and handles. One button - pneumatic valve enables the pump and the other two operate the stem of the presser forward or backward

---
